C12Adapter Opensource C++ Interface
|
Modem channel is a channel based on serial port. More...
Public Types | |
| enum | MModemResponse { MODEM_RESPONSE_UNKNOWN, MODEM_RESPONSE_OK, MODEM_RESPONSE_CONNECT, MODEM_RESPONSE_RING, MODEM_RESPONSE_NO_CARRIER, MODEM_RESPONSE_ERROR, MODEM_RESPONSE_TIMEOUT, MODEM_RESPONSE_NO_DIALTONE, MODEM_RESPONSE_BUSY, MODEM_RESPONSE_NO_ANSWER } |
| Possible modem response codes. More... | |
 Public Types inherited from MChannel | |
| enum | { CANCEL_COMMUNICATION_CHECK_OPTIMUM_INTERVAL = 1000 } |
Public Member Functions | |
| MChannelModem () | |
| Create a channel with initial parameters. | |
| virtual | ~MChannelModem () |
| Destroy channel modem. More... | |
| virtual void | Connect () |
| Connect to the meter, where connection means hook off, dialing phone number, checking for modem responses. More... | |
| virtual void | WaitForNextIncomingConnection (bool reinitialize=true) |
| When GetAutoAnswer true, wait for the incoming connection without disconnecting the channel. More... | |
| virtual void | Disconnect () |
| Disconnect channel. More... | |
| virtual bool | IsConnected () const |
| Returns true if channel is connected and false otherwise. More... | |
| virtual void | CheckIfConnected () |
| Throw an appropriate exception if the channel is not connected. More... | |
| const MByteString & | GetModemResponse () const |
| Full modem response after the successful connection, or after any successful control command. More... | |
| virtual void | CancelCommunication (bool callDisconnect=false) |
| Request canceling of the communication. More... | |
| void | HookOn () |
| Auxiliary function "hook on". More... | |
| void | SendCommand (const MByteString &command) |
| Send command to the modem and complete it with line completion char (see m_lineCompletionChar). More... | |
| MByteString | ReceiveResponse () |
| Receive response string from the modem after the command was sent. More... | |
| MModemResponse | ReceiveKnownResponse (int timeout) |
| Get the response which is enlisted in MModemResponse type definition. More... | |
| void | SendCommandCheckOK (const MByteString &command) |
| Send command and completion char then check response for OK. More... | |
| const MByteString & | GetAutoAnswerString () const |
| void | SetAutoAnswerString (const MByteString &autoAnswerString) |
| const MByteString & | GetInitString () const |
| void | SetInitString (const MByteString &initString) |
| const MByteString & | GetDialString () const |
| void | SetDialString (const MByteString &dialString) |
| const MByteString & | GetPhoneNumber () const |
| void | SetPhoneNumber (const MByteString &phoneNumber) |
| unsigned | GetDialTimeout () const |
| void | SetDialTimeout (unsigned timeout) |
| unsigned | GetCommandTimeout () const |
| void | SetCommandTimeout (unsigned timeout) |
| bool | GetMatchConnectBaud () const |
| void | SetMatchConnectBaud (bool doMatch) |
| Public Member Functions inherited from MChannelSerialPort | |
| MChannelSerialPort () | |
| Construct serial port channel. | |
| virtual | ~MChannelSerialPort () |
| Destructor. | |
| virtual void | FlushOutputBuffer (unsigned numberOfCharsInBuffer=UINT_MAX) |
| Ensure that the characters from the output buffer are sent. More... | |
| void | SetParameters (unsigned baud, int dataBits, char parity, int stopBits) |
| SetParameters is a convenience function for setting the properties baud rate, number of data bits, parity, and number of stop bits in a single call. | |
| bool | GetDCD () const |
| The current state of the DCD signal of the port. More... | |
| virtual MStdString | GetMediaIdentification () const |
| Return a string that will identify the media through which this channel is talking to. More... | |
| const MStdString & | GetPortName () const |
| void | SetPortName (const MStdString &portName) |
| unsigned | GetBaud () const |
| void | SetBaud (unsigned baud) |
| char | GetParity () const |
| void | SetParity (char p) |
| int | GetStopBits () const |
| void | SetStopBits (int stopBits) |
| int | GetDataBits () const |
| void | SetDataBits (int dataBits) |
| bool | GetCtsFlow () const |
| void | SetCtsFlow (bool isCtsFlow) |
| bool | GetDsrFlow () const |
| void | SetDsrFlow (bool isDsrFlow) |
| bool | GetDsrSensitivity () const |
| void | SetDsrSensitivity (bool isDsrSens) |
| char | GetDtrControl () const |
| void | SetDtrControl (char dtrControl) |
| char | GetRtsControl () const |
| void | SetRtsControl (char rtsControl) |
| MSerialPort & | GetPort () |
| const MSerialPort & | GetPort () const |
| Public Member Functions inherited from MChannel | |
| virtual MChannel * | CreateClone () const |
| Virtual copy constructor, creates the channel, which is a clone of current. More... | |
| virtual | ~MChannel () |
| The destructor is public, and virtual. More... | |
| void | WriteBytes (const MByteString &buffer) |
| Writes the data to the channel, and returns when the last byte has been sent by the software. More... | |
| void | WriteByte (Muint8 b) |
| Writes a byte to the channel, and returns when it has been sent. More... | |
| void | WriteBuffer (const char *buf, unsigned len) |
| Writes the data buffer to the channel, and returns when the last character has been sent by the software (but hardware might still need to do some work). More... | |
| Muint8 | ReadByte () |
| Read a single byte from the channel. More... | |
| void | ReadBuffer (char *buf, unsigned numberToRead) |
| Read an exact number of characters from the channel. More... | |
| void | Unread (const MVariant &byteOrBytes) |
| Return the given byte or bytes to the stream buffer so they get read at the next read operation. More... | |
| void | UnreadBuffer (const char *buff, unsigned size) |
| Return the given bytes to the stream buffer so they get read at the next read operation. More... | |
| MByteString | ReadBytes (unsigned numberToRead) |
| Read bytes directly from the communication channel. More... | |
| MByteString | ReadBytesUntil (const MByteString &terminatingString) |
| Read bytes from the channel until a specified sequence is read. More... | |
| MByteString | ReadBytesUntilAnyByte (const char *finisher, unsigned finisherSize, unsigned headerSize, unsigned footerSize) |
| Read bytes from the channel until a specified sequence is read. More... | |
| MByteString | ReadAllBytes () |
| Read an arbitrary number of characters from the channel, as much as available. More... | |
| void | ClearInputBuffer () |
| Immediately discards all the pending characters from the channel. More... | |
| void | ClearInputUntilSilence (unsigned milliseconds) |
| Keep reading and ignoring input until there is silence. More... | |
| void | CheckIfConnectedConst () const |
| Throw an appropriate exception if the channel is not connected, constant version. More... | |
| unsigned | GetCountBytesSent () const |
| Number of bytes sent through the channel since its creation or since the last ResetCounts(). More... | |
| unsigned | GetCountBytesReceived () const |
| The number of bytes received through the channel since creation or since the last ResetCounts(). More... | |
| void | ResetCounts () |
| Reset channel statistical data, so the counters become zeros. More... | |
| virtual void | WriteToMonitor (const MStdString &message) |
| Synchronously write a message to the monitor, if it is connected. More... | |
| void | EnterUninterruptibleCommunication (bool notify=true) |
| Enter a communication sequence that shall not be be interrupted with CancelCommunication call. More... | |
| void | LeaveUninterruptibleCommunication (bool notify=true) |
| Leave a communication sequence that shall not be be interrupted with CancelCommunication call. More... | |
| void | CheckIfOperationIsCancelled () |
| Check if the user has requested the termination of the communication, and whether the cancel operation lock is zero. More... | |
| void | Sleep (unsigned milliseconds) |
| Channel version of Sleep, a delay function that is aware of cancel communication event. More... | |
| unsigned | ReadWithTimeout (char *buf, unsigned size, unsigned timeout) |
| Read up to size bytes into buffer using the given timeout. More... | |
| bool | GetAutoAnswer () const |
| void | SetAutoAnswer (bool isAutoAnswer) |
| unsigned | GetAutoAnswerTimeout () const |
| void | SetAutoAnswerTimeout (unsigned timeout) |
| void | SetMonitor (MMonitor::Pointer monitor) |
| MMonitor::Pointer | GetMonitor () const |
| SHOW_INTERNAL bool | GetEcho () const |
| void | SetEcho (bool echo) |
| bool | GetSendEchoBytesToMonitor () const |
| void | SetSendEchoBytesToMonitor (bool doSend) |
| unsigned | GetIntercharacterTimeout () const |
| void | SetIntercharacterTimeout (unsigned timeout) |
| unsigned | GetReadTimeout () const |
| void | SetReadTimeout (unsigned timeout) |
| unsigned | GetWriteTimeout () const |
| void | SetWriteTimeout (unsigned timeout) |
| Public Member Functions inherited from MCOMObject | |
| virtual | ~MCOMObject () |
| Object destructor. | |
| virtual MStdStringVector | GetAllPropertyNames () const |
| Return the list of publicly available properties in MCOM syntax. More... | |
| virtual MStdStringVector | GetAllPersistentPropertyNames () const |
| Return the list of publicly available persistent properties in MCOM syntax. More... | |
| MStdString | GetPersistentPropertyValues (bool onlyNondefaults=false, bool excludeSecurityRelated=false) const |
| Get the string with the list of persistent property names and their values. More... | |
| void | SetPersistentPropertyValues (const MStdString &values) |
| Set the persistent properties for the object using the string with the following format: More... | |
| void | SetPropertyValues (const MDictionary &values) |
| Set the properties for the object using the property list object. More... | |
| void | WritePropertiesToMonitor () |
| Write all non-default values of protocol properties into monitor. More... | |
| MStdString | DoGetPersistentPropertyValues0 () const |
| Get the string with the whole list of persistent property names and their values. More... | |
| MStdString | DoGetPersistentPropertyValues1 (bool onlyNondefaults) const |
| Get the string with the list of persistent property names and their values. More... | |
| Public Member Functions inherited from MObject | |
| virtual | ~MObject () |
| Object destructor. | |
| virtual const MClass * | GetClass () const =0 |
| Get the final class of the object. More... | |
| virtual unsigned | GetEmbeddedSizeof () const |
| For embedded object types, return the size of the class. More... | |
| bool | IsEmbeddedObject () const |
| Tell if the object is of embedded kind. More... | |
| SHOW_INTERNAL MVariant | Call (const MStdString &name, const MVariant ¶ms) |
| Call the object service with parameters, given as variant. More... | |
| MVariant | Call0 (const MStdString &name) |
| Call the object service with no parameters. More... | |
| MVariant | Call1 (const MStdString &name, const MVariant &p1) |
| Call the object service with one parameter. More... | |
| MVariant | Call2 (const MStdString &name, const MVariant &p1, const MVariant &p2) |
| Call the object service with two parameter. More... | |
| MVariant | Call3 (const MStdString &name, const MVariant &p1, const MVariant &p2, const MVariant &p3) |
| Call the object service with three parameter. More... | |
| MVariant | Call4 (const MStdString &name, const MVariant &p1, const MVariant &p2, const MVariant &p3, const MVariant &p4) |
| Call the object service with four parameter. More... | |
| MVariant | Call5 (const MStdString &name, const MVariant &p1, const MVariant &p2, const MVariant &p3, const MVariant &p4, const MVariant &p5) |
| Call the object service with five parameter. More... | |
| MVariant | Call6 (const MStdString &name, const MVariant &p1, const MVariant &p2, const MVariant &p3, const MVariant &p4, const MVariant &p5, const MVariant &p6) |
| Call the object service with six parameter. More... | |
| virtual MVariant | CallV (const MStdString &name, const MVariant::VariantVector ¶ms) |
| Call the object service with parameters, given as variant vector. More... | |
| virtual bool | IsPropertyPresent (const MStdString &name) const |
| Tell if the property with the given name exists. | |
| virtual bool | IsServicePresent (const MStdString &name) const |
| Tell if the service with the given name exists. | |
| virtual MVariant | GetProperty (const MStdString &name) const |
| Get the property value using name of the property. More... | |
| virtual void | SetProperty (const MStdString &name, const MVariant &value) |
| Set the property using name of the property, and value. More... | |
| virtual void | SetPersistentPropertiesToDefault () |
| Set the persistent properties of the object to their default values. More... | |
| virtual MVariant | GetPersistentPropertyDefaultValue (const MStdString &name) const |
| Get the default value of persistent property with the name given. More... | |
| virtual void | SetPersistentPropertyToDefault (const MStdString &name) |
| Set the persistent property with the name given to default value. More... | |
| virtual const char * | GetType () const |
| Get the name of the type for the object (could be the same as class name). | |
| virtual void | SetType (const MStdString &) |
| Intentionally, it will set the name of the type for the object, but the service will not allow setting the name to anything other than the current name. More... | |
| virtual void | Validate () |
| Validate internal structures of the object. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from MChannelSerialPort | |
| static MStdStringVector | GetAvailablePortNames (bool addExtraInfo=false) |
| Return a collection of serial port names available at this computer. More... | |
| static MStdString | GetPortType (const MStdString &portName) |
| Get type based on the port name. More... | |
| Static Public Member Functions inherited from MObject | |
| static const MClass * | GetStaticClass () |
| Get the declared class of this particular object. More... | |
| static bool | IsClassPresent (const MStdString &name) |
| Tells if the given class name is available. More... | |
| Static Public Attributes inherited from MObject | |
| static const MClass | s_class |
| Class of MObject. | |
| Protected Member Functions inherited from MChannel | |
| MChannel () | |
| Construct the channel object from parent class. More... | |
| Protected Member Functions inherited from MCOMObject | |
| MCOMObject () | |
| Object constructor, protected as the class is abstract. | |
| Protected Member Functions inherited from MObject | |
| MObject () | |
| Object constructor, protected as the class is abstract. | |
| void | DoSetPersistentPropertiesToDefault (const MClass *staticClass) |
| Set the persistent properties to their default values for one object provided the class for that object. More... | |
Modem channel is a channel based on serial port.
Win-modems and the other modems that are not based on the serial port have to be separate classes. Among the COM port modems, only Hayes compatible modems are supported.
The connection attempt can take a long time to complete or time out. If the connection is queued with QConnect and committed asynchronously with QCommit(True), then the connection can be aborted with QAbort.
Possible modem response codes.
Not all modems can handle enumerated responses, but most of them can.
|
virtual |
Destroy channel modem.
|
virtual |
Request canceling of the communication.
This service is overloaded to support canceling of modem dialing. Disconnect will be called only if the parameter of the function is true.
Reimplemented from MChannel.
|
virtual |
Throw an appropriate exception if the channel is not connected.
The exception can be different depending on whether the connection was not made previously, or if the connection was unexpectedly terminated.
Reimplemented from MChannel.
|
virtual |
Connect to the meter, where connection means hook off, dialing phone number, checking for modem responses.
If the channel is configured with GetAutoAnswer false, then the channel attempts to connect using the configured GetPhoneNumber, GetBaud, GetInitString, GetDialString, and GetDialTimeout. An exception is thrown if the connection cannot be established during the Dial Timeout.
If the channel is configured with GetAutoAnswer true, the channel waits GetAutoAnswerTimeout for the connection to be established. If after the first ring, the connection cannot be established during GetDialTimeout, then the channel continues to wait for the remaining Auto Answer Timeout for another call. If the connection cannot be established during the Auto Answer Timeout, an exception is thrown.
Reimplemented from MChannelSerialPort.
|
virtual |
Disconnect channel.
This service can be called as many times as the user wants. Not exception will be thrown. Disconnect means hook on.
Reimplemented from MChannelSerialPort.
|
inline |
The AT command used to put the modem into Auto Answer mode. The channel must also be configured with SetAutoAnswer true.
The connection attempt can take a long time to complete or time out. If the connection is queued with QConnect and committed asynchronously with QCommit(True), then the connection can be aborted with QAbort.
|
inline |
Command timeout.
Number of seconds to wait for the completion of a command until an answer is received.
|
inline |
The string that initiates dialing, typically this is the ATD command. The "DialString" and "PhoneNumber" are combined to yield the full dialing command that is sent to the modem.
|
inline |
Dial timeout.
Number of seconds to wait for the connection after dialing the phone number. SetAutoAnswer must be False for the channel to make an outbound call. This property is not used for inbound calls (when Auto Answer = True).
The connection attempt can take a long time to complete or time out. If the connection is queued with QConnect and committed asynchronously with QCommit(True), then the connection can be aborted with QAbort.
|
inline |
This is the modem initialization string sent to the modem prior to making a phone call (GetAutoAnswer = False) or prior to waiting for a phone call (GetAutoAnswer = True). Not all modems support the same commands, and the InitString may need to be tuned for your particular modem. For our MODEM channel implementation, the modem needs to be told to turn echo off, return verbal result codes, track the DCD state, and hang up when the DTR line is dropped. All of these modem commands are included in the InitString default value and are described in the Default Value section below.
|
inline |
Whether to match port and modem baud rates.
When this flag is true, then during connection, the CONNECT response from the meter is parsed in order to recognize the line connect speed. If the number is present, the software tries to set the modem speed to match the connect speed (or to be slightly below it), so there is no need for the flow control to be imposed between the modem and the computer. This is rarely needed, but is available for those internal modems which do not support flow control.
If the flag is set to false, no attempt to match port and modem baud rates is made.
|
inline |
Full modem response after the successful connection, or after any successful control command.
All non-printable characters will be replaced with blanks. The modem can be configured to respond with numeric codes instead of verbs, however MeteringSDK can not interpret them and will throw an "unknown response from the modem" error.
The modem response is the response sent by the modem in response to a MeteringSDK Connect attempt. The response could contain text like CONNECT 2400, ERROR, BUSY, NO CARRIER, etc. anything that the modem will respond with.
This property will be an empty string if queried before the connect attempt or if MeteringSDK did not get the modem response during the connect attempt.
|
inline |
The phone number to be dialed. Typically, this would be just a phone number like 555-5555, but it can contain a number of control characters, like P, T, comma, etc. The "DialString" and "PhoneNumber" are combined to yield the full dialing command that is sent to the modem.
| void MChannelModem::HookOn | ( | ) |
Auxiliary function "hook on".
Hook on is made by setting DTR low, then high, which works on the most of modems. "+++" command is not used.
|
virtual |
Returns true if channel is connected and false otherwise.
Can be called at any time.
Reimplemented from MChannelSerialPort.
| MModemResponse MChannelModem::ReceiveKnownResponse | ( | int | timeout | ) |
Get the response which is enlisted in MModemResponse type definition.
Possibly return MODEM_RESPONSE_UNKNOWN.
| MByteString MChannelModem::ReceiveResponse | ( | ) |
Receive response string from the modem after the command was sent.
| void MChannelModem::SendCommand | ( | const MByteString & | command | ) |
Send command to the modem and complete it with line completion char (see m_lineCompletionChar).
| void MChannelModem::SendCommandCheckOK | ( | const MByteString & | command | ) |
Send command and completion char then check response for OK.
If no response is received before 'm_commandTimeout' timeout expires, or the response is not OK then the appropriate exception will be raised.
|
inline |
The AT command used to put the modem into Auto Answer mode. The channel must also be configured with SetAutoAnswer true.
The connection attempt can take a long time to complete or time out. If the connection is queued with QConnect and committed asynchronously with QCommit(True), then the connection can be aborted with QAbort.
|
inline |
Command timeout.
Number of seconds to wait for the completion of a command until an answer is received.
|
inline |
The string that initiates dialing, typically this is the ATD command. The "DialString" and "PhoneNumber" are combined to yield the full dialing command that is sent to the modem.
|
inline |
Dial timeout.
Number of seconds to wait for the connection after dialing the phone number. SetAutoAnswer must be False for the channel to make an outbound call. This property is not used for inbound calls (when Auto Answer = True).
The connection attempt can take a long time to complete or time out. If the connection is queued with QConnect and committed asynchronously with QCommit(True), then the connection can be aborted with QAbort.
|
inline |
This is the modem initialization string sent to the modem prior to making a phone call (GetAutoAnswer = False) or prior to waiting for a phone call (GetAutoAnswer = True). Not all modems support the same commands, and the InitString may need to be tuned for your particular modem. For our MODEM channel implementation, the modem needs to be told to turn echo off, return verbal result codes, track the DCD state, and hang up when the DTR line is dropped. All of these modem commands are included in the InitString default value and are described in the Default Value section below.
|
inline |
Whether to match port and modem baud rates.
When this flag is true, then during connection, the CONNECT response from the meter is parsed in order to recognize the line connect speed. If the number is present, the software tries to set the modem speed to match the connect speed (or to be slightly below it), so there is no need for the flow control to be imposed between the modem and the computer. This is rarely needed, but is available for those internal modems which do not support flow control.
If the flag is set to false, no attempt to match port and modem baud rates is made.
|
inline |
The phone number to be dialed. Typically, this would be just a phone number like 555-5555, but it can contain a number of control characters, like P, T, comma, etc. The "DialString" and "PhoneNumber" are combined to yield the full dialing command that is sent to the modem.
|
virtual |
When GetAutoAnswer true, wait for the incoming connection without disconnecting the channel.
A typical server application sequence that uses this call:
| reinitialize | Tells if the channel is reinitialized for each new incoming connection. |
Reimplemented from MChannelSerialPort.
1.8.11
